Single-lens reflex digital camera

Nikon F mount (with AF coupling and AF contacts)

Nikon DX format; focal length in 35 mm [135] format equivalent to approx. 1.5x that of lenses with FX format angle of view

24.1 million

23.5 x 15.6 mm CMOS sensor

24.69 million

Image sensor cleaning, Image Dust Off reference data (optional Capture NX 2 software required)

DX (24 x 16) image area 6000 x 4000 (L), 4496 x 3000 (M), 2992 x 2000 (S) 1.3x (18 x 12) image area 4800 x 3200 (L), 3600 x 2400 (M), 2400 x 1600 (S) Photographs with image area of DX (24 x 16) taken in movie live view 6000 x 3368 (L), 4496 x 2528 (M), 2992 x 1860 (S) Photographs with image area of 1.3x (18 x 12) taken in movie live view 4800 x 2696 (L), 3600 x 2024 (M), 2400 x 1344 (S)

NEF (RAW): 12 or 14 bit, lossless compressed or compressed JPEG: JPEG-Baseline compliant with fine (approx. 1 : 4), normal (approx. 1 : 8), or basic (approx. 1 : 16) compression (Size priority); Optimal quality compression available NEF (RAW) + JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats

Standard, Neutral, Vivid, Monochrome, Portrait, Landscape; selected Picture Control can be modified; storage for custom Picture Controls

SD (Secure Digital) and UHS-I compliant SDHC and SDXC memory cards

Slot 2 can be used for overflow or backup storage or for separate storage of copies created using NEF+JPEG; pictures can be copied between cards.

DCF (Design Rule for Camera File System) 2.0, DPOF (Digital Print Order Format), Exif (Exchangeable Image File Format for Digital Still Cameras) 2.3, PictBridge

Eye-level pentaprism single-lens reflex viewfinder

Approx. 100% horizontal and 100% vertical

Approx. 0.94x (50 mm f/1.4 lens at infinity, -1.0 m-1)

19.5 mm (-1.0 m-1; from center surface of viewfinder eyepiece lens)

-2 - +1 m-1

Type B BriteView Clear Matte Mark II screen with AF area brackets (framing grid can be displayed)

Quick return

Pressing depth-of-field preview button stops lens aperture down to value selected by user (A and M modes) or by camera (other modes)

Instant return, electronically controlled

Compatible with AF NIKKOR lenses, including type G and D lenses (some restrictions apply to PC lenses) and DX lenses, AI-P NIKKOR lenses, and non-CPU AI lenses (A and M modes only). IX NIKKOR lenses, lenses for the F3AF, and non-AI lenses can not be used. The electronic rangefinder can be used with lenses that have a maximum aperture of f/5.6 or faster (the electronic rangefinder supports the center 1 focus point with lenses that have a maximum aperture of f/8 or faster).

Electronically-controlled vertical-travel focal-plane shutter

1/8000 - 30 s in steps of 1/3 or 1/2 EV, bulb, time, X250

X=1/250 s; synchronizes with shutter at 1/320 s or slower (flash range drops at speeds between 1/250 and 1/320 s)

Single frame (S), continuous low speed (CL), continuous high speed (CH), quiet shutter-release (Q), self-timer, mirror up (MUP); interval timer photography supported

JPEG and 12-bit NEF (RAW) images recorded with DX (24 x 16) selected for Image area CL: 1 - 6 fps, CH: 6 fps JPEG and 12-bit NEF (RAW) images recorded with 1.3x (18 x 12) selected for Image area CL: 1 - 6 fps, CH: 7 fps 14-bit NEF (RAW) images recorded with DX (24 x 16) selected for Image area CL: 1 - 5 fps, CH: 5 fps 14-bit NEF (RAW) images recorded with 1.3x (18 x 12) selected for Image area CL: 1 - 6 fps, CH: 6 fps

2 s, 5 s, 10 s, 20 s; 1 - 9 exposures at intervals of 0.5, 1, 2, or 3 s

Delayed remote, quick-response remote, remote mirror-up

TTL exposure metering using 2016-pixel RGB sensor

Matrix: 3D color matrix metering II (type G and D lenses); color matrix metering II (other CPU lenses); color matrix metering available with non-CPU lenses if user provides lens data Center-weighted: Weight of 75% given to 8 mm circle in center of frame. Diameter of circle can be changed to 6, 10, or 13 mm, or weighting can be based on average of entire frame (non-CPU lenses use 8-mm circle) Spot: Meters 3.5 mm circle (about 2.5% of frame) centered on selected focus point (on center focus point when non-CPU lens is used)

Matrix or center-weighted metering: 0 - 20 EV Spot metering: 2 - 20 EV

Combined CPU and AI

Auto modes (auto; auto (flash off)); programmed auto with flexible program (P); shutter-priority auto (S); aperture-priority auto (A); manual (M); scene modes (portrait; landscape; child; sports; close up; night portrait; night landscape; party/indoor; beach/snow; sunset; dusk/dawn; pet portrait; candlelight; blossom; autumn colors; food); special effects modes (night vision; color sketch; miniature effect; selective color; silhouette; high key; low key); U1 (user settings 1); U2 (user settings 2)

Can be adjusted by -5 - +5 EV in increments of 1/3 or 1/2 EV in P, S, A, and M modes

2 - 5 frames in steps of 1/3, 1/2, 2/3, 1, 2, or 3 EV

2 - 5 frames in steps of 1/3, 1/2, 2/3, 1, 2, or 3 EV

2 - 5 frames in steps of 1, 2, or 3

2 frames using selected value for one frame or 3 frames using preset values for all frames

Luminosity locked at detected value with AE-L/AF-L button

ISO 100 - 6400 in steps of 1/3 or 1/2 EV. Can also be set to approx. 0.3, 0.5, 0.7, 1, or 2 EV (ISO 25600 equivalent) above ISO 6400; auto ISO sensitivity control available

Auto, Extra high, High, Normal, Low, Off

Nikon Advanced Multi-CAM 3500DX autofocus sensor module with TTL phase detection, fine-tuning, 51 focus points (including 15 cross-type sensors; the center 1 focus point is available at apertures slower than f/5.6 and faster than f/8 or at f/8), and AF-assist illuminator (range approx. 0.5 - 3m/1 ft 8 in. - 9 ft 10 in.)

-2 - +19 EV (ISO 100, 20 °C/68 °F)

Autofocus (AF): Single-servo AF (AF-S); continuous-servo AF (AF-C); auto AF-S/AF-C selection (AF-A); predictive focus tracking activated automatically according to subject status Manual focus (M): Electronic rangefinder can be used

Can be selected from 51 or 11 focus points

Single-point AF; 9-, 21-, or 51-point dynamic-area AF, 3D-tracking, auto-area AF

Focus can be locked by pressing shutter-release button halfway (single-servo AF) or by pressing AE-L/AF-L button

Auto, portrait, child, close up, night portrait, party/indoor, pet portrait, color sketch: Auto flash with auto pop-up P, S, A, M, food: Manual pop-up with button release

Approx. 12/39, 12/39 with manual flash (m/ft, ISO 100, 20 °C/68 °F)

TTL: i-TTL flash control using 2016-pixel RGB sensor is available with built-in flash and SB-910, SB-900, SB-800, SB-700, SB-600, or SB-400; i-TTL balanced fill-flash for digital SLR is used with matrix and center-weighted metering, standard i-TTL flash for digital SLR with spot metering

Auto, auto with red-eye reduction, auto slow sync, auto slow sync with red-eye reduction, fill-flash, red-eye reduction, slow sync, slow sync with red-eye reduction, rear-curtain with slow sync, rear-curtain sync, off; Auto FP High-Speed Sync supported

-3 - +1 EV in increments of 1/3 or 1/2 EV

Lights when built-in flash or optional flash unit is fully charged; flashes after flash is fired at full output

ISO 518 hot-shoe with sync and data contacts and safety lock

Advanced Wireless Lighting supported with: - SB-910, SB-900, SB-800, or SB-700 as a master flash and SB-600 or SB-R200 as remotes, or SU-800 as commander - Built-in flash can serve as master flash in commander mode Auto FP High-Speed Sync and modeling illumination supported with all CLS-compatible flash units except SB-400; Flash Color Information Communication and FV lock supported with all CLS-compatible flash units

AS-15 sync terminal adapter (available separately)

Auto (2 types), incandescent, fluorescent (7 types), direct sunlight, flash, cloudy, shade, preset manual (up to 6 values can be stored, spot white balance measurement available during live view), choose color temperature (2500 K - 10000 K), all with fine-tuning

Live view photography (still images), movie live view (movies)

Autofocus (AF): Single-servo AF (AF-S); full-time-servo AF (AF-F) Manual focus (M)

Face-priority AF, wide-area AF, normal-area AF, subject-tracking AF

Contrast-detect AF anywhere in frame (camera selects focus point automatically when face-priority AF or subject-tracking AF is selected)

TTL exposure metering using main image sensor

Matrix

1920 x 1080; 60i (59.94 fields/s)/ 50i (50 fields/s) * 1920 x 1080; 30 p (progressive), 25p, 24p 1280 x 720; 60p, 50p Actual frame rates for 60p, 50p, 30p, 25p, and 24p are 59.94, 50, 29.97, 25, and 23.976 fps respectively; options support both high and normal image quality * Available only when 1.3x (18 x 12) is selected for Image area. Sensor output is about 60 or 50 fps.

MOV

H.264/MPEG-4 Advanced Video Coding

Linear PCM

Built-in or external stereo microphone; sensitivity adjustable

8-cm/3.2-in., approx. 1229 k-dot (VGA; 640 x 4 x 480 = 1,228,800 dots), TFT monitor with approx. 170° viewing angle, approx. 100% frame coverage, and brightness adjustment

Full-frame and thumbnail (4, 9, or 72 images or calendar) playback with playback zoom, movie playback, photo and/or movie slide shows, histogram display, highlights, photo information, GPS data display, and auto image rotation

Hi-Speed USB

HDMI mini connector (Type C)

Wireless remote controller: WR-1 and WR-R10 (available separately) Remote cord: MC-DC2 (available separately) GPS unit: GP-1 (available separately)

Stereo mini-pin jack (3.5 mm diameter; plug-in power supported)

Stereo mini-pin jack (3.5 mm diameter)

Arabic, Bengali, Chinese (Simplified and Traditional), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hindi, Hungarian, Indonesian, Italian, Japanese, Korean, Norwegian, Persian, Polish, Portuguese (European and Brazilian), Romanian, Russian, Spanish, Swedish, Tamil, Thai, Turkish, Ukrainian, Vietnamese

One rechargeable Li-ion EN-EL15 battery

Optional MB-D15 multi-power battery pack with one rechargeable Nikon EN-EL15 Li-ion battery or six AA alkaline, Ni-MH, or lithium batteries

EH-5b AC adapter; requires EP-5B power connector (available separately)

1/4 in. (ISO 1222)

Approx. 135.5 x 106.5 x 76 mm (5.3 x 4.2 x 3.0 in.)

Approx. 765 g (1 lb 11.0 oz) with battery and memory card but without body cap; approx. 675 g (1 lb 7.8 oz; camera body only)

0°C - 40°C (+32°F - 104°F)

85% or less (no condensation)

EN-EL15 rechargeable Li-ion battery (with terminal cover), MH-25 battery charger, DK-5 eyepiece cap, AN-DC1 strap, UC-E6 USB cable, BS-1 accessory shoe cover, DK-23 rubber eyecup, BF-1B body cap, ViewNX 2 CD, User's Manual
