· Compact and lightweight design
· Quick focusing in Live View mode with Dual pixel CMOS AF
· Vari-angle touchscreen LCD
· Wi-Fi / NFC / Bluetooth low energy
| Type | ||
| Type | Digital, single-lens reflex, AF / AE camera with built-in flash | |
| Recording media | SD memory card, SDHC memory card, SDXC memory card * Compatible with UHS-I | |
| Sensor Size | APS-C | |
| Image sensor size | 22.3 x 14.9mm | |
| Compatible lenses | Canon EF lenses (including EF-S lenses) * Excluding EF-M lenses (35 mm-equivalent focal length is approx. 1.6 times the lens focal length) | |
| Lens mount | Canon EF mount | |
| Image Sensor | ||
| Type | CMOS sensor | |
| Effective pixels | 24.2megapixel | |
| Aspect ratio | 3:2 | |
| Dust delete feature | Auto, Manual, Dust Delete Data appending | |
| Recording System | ||
| Recording format | Design rule for Camera File System (DCF) 2.0 | |
| Image type | JPEG, RAW (14-bit Canon original) RAW+JPEG Large simultaneous recording possible | |
| Recorded pixels | L (Large): | 24.0 megapixel (6 000 x 4 000) |
| M (Medium): | Approx. 10.6megapixel (3 984 x 2 656) | |
| S1 (Small 1): | Approx. 5.9megapixels (2 976 x 1984) | |
| S2 (Small 2): | Approx. 3.8megapixel (2 400 x 1 600) | |
| RAW: | 24.0 megapixel (6 000 x 4 000) | |
| Image Processing During Shooting | ||
| Picture Style | Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined 1 - 3 | |
| White balance | Auto (Ambience priority), Auto (White priority), Preset (Daylight, Shade, Cloudy, Tungsten light, White fluorescent light, Flash), Custom White balance correction, and White balance bracketing provided * Flash color temperature information transmission possible | |
| Noise reduction | Applicable to long exposures and high ISO speed shots | |
| Automatic image brightness correction | Auto Lighting Optimizer | |
| Highlight tone priority | Provided | |
| Lens aberration correction | Peripheral illumination correction, Chromatic aberration correction, Distortion correction, Diffraction correction | |
| Viewfinder | ||
| Type | Eye-level pentamirror | |
| Coverage | Vertical / Horizontal 95% (with Eye point approx. 19mm) | |
| Magnification | 0.87x (-1m-1 with 50mm lens at infinity) | |
| Eye point | 19mm (from eyepiece lens center at -1m-1) | |
| Built-in dioptric adjustment | -3.0 - +1.0m-1 (dpt) | |
| Focusing screen | Fixed, Precision Matte | |
| Mirror | Quick-return type | |
| Depth-of-field preview | Provided | |
| Autofocus | ||
| Type | TTL secondary image-registration, phase-difference detection with the dedicated AF sensor | |
| AF points | 9 point AF (Center point: cross-type and vertical line sensitive when supporting f/2.8) | |
| Focusing brightness range | EV -0.5 - 18 (with the center AF point supporting f/2.8, One-Shot AF, at room temperature, ISO 100) | |
| AF operation | One-Shot AF, AI Servo AF, AI Focus AF, Manual focusing (MF) | |
| AF-assist beam | Small series of flashes fired by built-in flash | |
| Exposure Control | ||
| Metering modes | 63 zone TTL open-aperture metering
| |
| Metering brightness range | EV 1 - 20 (at room temperature, ISO 100) | |
| Shooting mode | Basic Zone modes: | Scene Intelligent Auto, Flash Off, Creative Auto, Special scene modes (Portrait, Group Photo, Landscape, Sports, Kids, Close-up, Food, Candlelight, Night Portrait, Handheld Night Scene, HDR Backlight Control), Creative filters (Grainy B / W, Soft focus, Fish-eye effect, Water painting effect, Toy camera effect, Miniature effect, HDR art standard, HDR art vivid, HDR art bold, HDR art embossed) |
| Creative Zone modes: | Program AE, Shutter-priority AE, Aperture-priority AE, Manual exposure | |
| ISO speed (Recommended exposure index) | Basic Zone modes: ISO speed set automatically Creative Zone modes: ISO Auto, ISO 100 - ISO 25600 set manually (whole-stop increments), and ISO expansion to H (equivalent to ISO 51200) provided | |
| Exposure compensation | Manual: ±5* stops in 1/3- or 1/2-stop increments * ±3 stops with [Shooting screen: Guided] set AEB: ±2 stops in 1/3- or 1/2-stop increments (can be combined with manual exposure compensation) | |
| AE lock | Auto: Applied in One-Shot AF with evaluative metering when focus is achieved | |
| Shutter | ||
| Type | Electronically-controlled, focal-plane shutter | |
| Shutter Speed | 1/4 000s to 30s (Total shutter speed range. Available range varies by shooting mode.), Bulb, X-sync at 1/200s | |
| Flash | ||
| Built-in flash | Retractable, auto pop-up flash Guide No.: | 9.8 / 32.1 (ISO 100, in m/ft) |
| Flash coverage: | 18mm lens angle of view | |
| Recharge time: | 3s | |
| External flash | Compatible with EX-series Speedlites | |
| Flash metering: | E-TTL II autoflash | |
| Flash exposure compensation | ±2 stops in 1/3 or 1/2 stop increments | |
| FE lock | Provided | |
| PC terminal | None | |
| Drive System | ||
| Drive modes | Single shooting, Continuous shooting, Silent single shooting, Silent continuous shooting, 10s self-timer/ remote control*, 2s delay, 10s delay with continuous shooting *When Wireless Remote Control BR-E1 (sold separately) is used. | |
| Continuous shooting speed | Maximum 5.0 shots/s* * Maximum 3.5 shots/s during Live View shooting or when [Servo AF] is set. Silent continuous shooting: Maximum 2.5 shots/s | |
| Maximum burst | JPEG Large / Fine: | Full (Full) |
| RAW: | 6 shots | |
| RAW+JPEG Large / Fine: | 6 shots | |
| * Figures are based on Canon's testing standards (3:2 aspect ratio, ISO 100 and Standard Picture Style) using a Canon’s standard testing 8GB card. * Figures in parentheses are the number of shots when a Canon's standard testing UHS-I 16GB card is used. * "Full" indicates that shooting is possible until the card becomes full. | ||
| Live View Shooting | ||
| Focus method | Dual Pixel CMOS AF system | |
| AF method | Face+Tracking, Smooth zone, Live 1-point AF Manual focus (5x / 10x magnification possible) | |
| AF operation | One-Shot AF, Servo AF | |
| Focusing brightness range | EV -2 - 18 (at room temperature, ISO 100, One-Shot AF) | |
| Touch shutter | Provided | |
| Metering mode | Evaluative metering (315 zones), Partial metering (6.0% of Live View screen), Spot metering (2.6% of Live View screen), Center-weighted average metering | |
| Metering brightness range | EV 0 - 20 (at room temperature, ISO 100) | |
| Exposure compensation | ±3 stops in 1/3-stop or 1/2-stop increments | |
| Creative Filters | Provided | |
| Grid display | Three types | |
| Movie Shooting | ||
| Recording format | MP4 * Time-lapse movie shooting: MOV | |
| Movie | MPEG-4 AVC / H.264 Variable (average) bit rate | |
| Audio | AAC | |
| Recording size and frame rate | 1920 x 1080 (Full HD): | 59.94p / 50.00p / 29.97p / 25.00p / 23.98p |
| 1280 x 720 (HD): | 59.94p / 50.00p / 29.97p / 25.00p | |
| 640 x 480 (VGA): | 29.97p / 25.00p | |
| Compression method | IPB (Standard), IPB (Light) * Time-lapse movie shooting: ALL-I | |
| Bit rate | Full HD (59.94p / 50.00p) / IPB (Standard) | Approx. 60Mbps |
| Full HD (29.97p / 25.00p / 23.98p) / IPB (Standard) | Approx. 30Mbps | |
| Full HD (29.97p / 25.00p) / IPB (Light) | Approx. 12Mbps | |
| HD (59.94p / 50.00p) / IPB (Standard) | Approx. 26Mbps | |
| HD (29.97p / 25.00p) / IPB (Light) | Approx. 4Mbps | |
| VGA (29.97p / 25.00p) (Standard) | Approx. 9Mbps | |
| VGA (29.97p / 25.00p) (Light) | Approx. 3Mbps | |
| HDR movie | Approx. 30Mbps | |
| Time-lapse movie | Approx. 90Mbps | |
| Focus system | Dual pixel CMOS AF system | |
| AF method | Face+Tracking, Smooth zone, Live 1 point AF Manual focus (approx. 5x / 10x magnification available for focus check) | |
| Movie Servo AF | Provided | |
| Digital zoom | 3x - 10x | |
| Focusing brightness range | EV -2 - 18 (at room temperature, ISO 100, One-Shot AF) | |
| Metering mode | Center-weighted average and Evaluative metering with the image sensor * Automatically set by the AF method | |
| Metering brightness range | EV 0 - 20 (at room temperature, ISO 100, with center weighted average metering) | |
| Exposure control | Autoexposure shooting (Program AE for movie shooting) and manual exposure | |
| Exposure compensation | ±3 stops in 1/3- or 1/2-stop increments | |
| ISO speed (Recommended exposure index) | For autoexposure shooting: | ISO 100 - ISO 12800 set automatically. In Creative Zone modes, the upper limit is expandable to H (equivalent to ISO 25600). |
| For manual exposure: | ISO Auto (ISO 100 – ISO 12800 set automatically), ISO 100 - ISO 12800 set manually (whole-stop increments), expandable to H (equivalent to ISO 25600) | |
| ISO speed settings | Maximum limit for ISO Auto settable | |
| HDR movie shooting | Possible | |
| Video snapshots | Settable to 2s / 4s / 8s | |
| Creative filters for movies | Dream, Old Movies, Memory, Dramatic B&W, Miniature effect movie | |
| Sound recording | Built-in stereo microphones, external stereo microphone terminal provided Sound-recording level adjustable, wind filter provided, attenuator provided | |
| Grid display | Three types | |
| Time-lapse movie | Shooting interval (h:m:s), Number of shots, Auto exposure (Fixed 1st frame, Each frame), LCD auto off, Beep as image shot settable | |
| LCD Monitor | ||
| Type | TFT color liquid-crystal monitor | |
| Monitor size and dots | Wide, 7.7cm(3.03 in) (3:2) with approx. 1.04 million dots | |
| Brightness adjustment | Manual (7 levels) | |
| Interface languages | 25 | |
| Touch screen technology | Capacitive sensing | |
| Playback | ||
| Image display format | Single-image display (without shooting information), Single-image display (with basic information), Single image display (Shooting information displayed: Detailed information, Lens / histogram, White balance, Picture Style 1, Picture Style 2, Color space/noise reduction, Lens aberration correction), Index display (4 / 9 / 36 / 100 images) | |
| Zoom magnification | 1.5x - 10x | |
| Highlight alert | Overexposed highlights blink | |
| AF point display | Provided (may not be displayed depending on shooting conditions) | |
| Image search | Search conditions settable (Rating, Date, Folder, Protect, File type) | |
| Image browsing methods | Single image, 10 images, specified number, date, folder, movies, stills, protect, rating | |
| Image rotation | Possible | |
| Rating | Provided | |
| Movie playback | Possible (LCD monitor, HDMI), built-in speaker | |
| Image protect | Possible | |
| Slide show | Automatically play back all images or the images that match search conditions | |
| Background music | Selectable for slide shows and movie playback | |
| Post-Processing of Images | ||
| Creative filters | Grainy B/W, Soft focus, Fish-eye effect, Art bold effect, Water painting effect, Toy camera effect, Miniature effect | |
| Resize | Possible | |
| Cropping | Possible | |
| Print Ordering | ||
| DPOF | DPOF Version 1.1 compliant | |
| Wi-Fi | ||
| Standards compliance | IEEE 802.11b/g/n | |
| Transmission method | DS-SS modulation (IEEE 802.11b) OFDM modulation (IEEE 802.11g/n) | |
| Transmission range | 15m / 49.2ft *When communicating with a smartphone *With no obstructions between the transmitting and receiving antennas and no radio interference | |
| Transmission frequency (central frequency) | Frequency: 2 412 to 2 462MHz Channels: 1 to 11ch | |
| Connection method | Camera access point mode, infrastructure* * Wi-Fi Protected Setup supported | |
| Security | Authentication method: Open system, Shared key, WPA / WPA2-PSK Encryption: WEP, TKIP, AES | |
| Communication with a smartphone | Images can be viewed, controlled, and received using a smartphone. Remote control of the camera using a smartphone is possible. Images can be sent to a smartphone. | |
| Transfer images between cameras | Transferring one image, Transferring selected images, Transferring resized images | |
| Connect to Connect Station | Images can be sent to and saved on Connect Station. | |
| Remote operation using EOS Utility | Remote control functions and image viewing functions of EOS Utility can be used wirelessly. | |
| Print from Wi-Fi printers | Images can be sent to a Wi-Fi printer. | |
| Send images to a Web service | Images in the camera or links to images can be sent to registered Web services. | |
| NFC | ||
| Standards compliance | NFC Forum Type 3/4 Tag compliant (dynamic) | |
| Bluetooth | ||
| Standards compliance | Bluetooth Specification Version 4.1 compliant (Bluetooth low energy technology) | |
| Transmission method | GFSK modulation | |
| Customization Features | ||
| Custom Functions | 11 | |
| My Menu | Up to 5 screens can be registered | |
| Copyright information | Text entry and appending possible | |
| Interface | ||
| DIGITAL terminal | Computer communication (Hi-Speed USB equivalent), Connect Station CS100 connection | |
| HDMI mini OUT terminal | Type C (Auto switching of resolution), CEC-compatible | |
| External microphone IN terminal | 3.5mm diameter stereo mini-jack | |
| Remote control terminal | For Remote Switch RS-60E3 | |
| Wireless remote control | Compatible with Wireless Remote Control BR-E1 (Bluetooth connection) | |
| Eye-Fi card | Compatible | |
| Power | ||
| Battery | Battery Pack LP-E17 (Quantity 1) * AC power usable with household power outlet accessories. | |
| Number of possible shots (Based on CIPA testing standards) | With viewfinder shooting: | Approx. 650 shots at room temperature (23°C / 73°F) Approx. 620 shots at low temperatures (0°C / 32°F) |
| With Live View shooting: | Approx. 260 shots at room temperature (23°C / 73°F) Approx. 240 shots at low temperatures (0°C / 32°F) | |
| Movie shooting time: | Approx. 2h at room temperature (23°C / 73°F) Approx. 1h 45m at low temperatures (0°C / 32°F) | |
| Dimensions and Weight | ||
| Dimensions (W x H x D) | 122.4 x 92.6 x 69.8mm / 4.82 x 3.65 x 2.75in | |
| Weight | Black | 453g / 15.98oz (Including battery and card) 406g / 14.32oz (Body only) |
| Operation Environment | ||
| Working temperature range | 0°C - 40°C / 32°F - 104°F | |
| Working humidity | 85% or less | |
